Hàng xách tay từ Mỹ
Tình trạng: Hàng trưng bày mới 99%
| Connections |
| SDI Video Input |
1 x 10 bit SD/HD switchable. |
| SDI Video Output |
1 x 10 bit SD/HD switchable. |
| Analog Video Input |
None |
| Analog Video Output |
None |
| HDMI Video Input |
None |
| HDMI Video Output |
1 x HDMI type A connector |
| Analog Audio Input |
None |
| Analog Audio Output |
None |
| AES/EBU Audio Input |
None |
| AES/EBU Audio Output |
None |
| SDI Audio Input |
8 Channels embedded in SD and HD |
| SDI Audio Output |
8 Channels embedded in SD and HD |
| HDMI Audio Input |
None |
| HDMI Audio Output |
2 Channels embedded in SD and HD. |
| Computer Interface |
USB 3.0 |
| Sync Input |
Blackburst in SD, 720p50, 720p59.94, 1080i50 and 1080i59.94 formats or Tri-Sync in any HD format. |
| Device Control |
Sony™ compatible RS422 deck control ports. Serial ports TxRx direction reversible under software control. |
| Standards |
| SD Format Support |
625/25 PAL, 525/29.97 NTSC and 525/23.98 NTSC |
| HD Format Support |
720p50, 720p59.94, 720p60, 1080PsF23.98, 1080p23.98, 1080PsF24, 1080p24, 1080PsF25, 1080p25, 1080PsF29.97, 1080p29.97, 1080PsF30, 1080p30, 1080i50, 1080i59.94, and 1080i60. |
| 2K Format Support |
None |
| SDI Compliance |
SMPTE 259M and SMPTE 292M. |
| SDI Metadata Support |
VITC read for 3:2 pulldown removal. VANC capture and playback using up to 3 lines of video in file. HD RP188. Closed captioning. |
| Video Sampling |
4:02:02 |
| Audio Sampling |
Television standard sample rate of 48 kHz and 24 bit. |
| Color Precision |
10-bit |
| Color Space |
REC 601, REC 709 |
| HDMI Color Precision |
10 bit |
| HDMI Resolution |
Pixel for pixel HD resolution input to connected device. |
| HDMI Configuration |
HDMI automatically configures to connected display. |
| Multiple Rate support |
SDI and HDMI video connections are switchable between standard definition and high definition. SDI switches between 270 Mb/s standard definition SDI and 1.5 Gb/s HD-SDI. |
| Copy Protection |
For legal reasons HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content. |
| Processing |
| Colorspace Conversion |
Hardware based real time. |
| 3D Processing |
None |
| HD Down Conversion |
Software based down conversion during video playback. |
| HD Up Conversion |
Real time standard definition to 1080HD and 720HD during video capture. |
| HD Cross Conversion |
Real time 720HD to 1080HD during video capture. |
| Real Time Effects |
Adobe® Premiere Pro® Mercury Playback Engine effects in DV, MJPEG, DVCPRO HD, DSLR, AVCHD, XDCAM, XDCAM HD and uncompressed. |
| Extras |
| Software Included |
Media Express, Disk Speed Test, Blackmagic Control Panel and Blackmagic driver on Windows™. |
| Firmware Upgrade |
Firmware built into software driver. Loaded at system start or via updater software. |
| Installation |
Requires a computer with onboard USB 3.0, or a USB 3.0 PCI Express 2.0 card. Does not support USB 2.0 capture and playback. Please check the Support pages to see the full system requirements. |
| Operating System Compatibility |
Compatible with Microsoft Windows 7™. |
